S Series – 24VDC

Applications

HVAC, molding injection machine, big storage management,
packaging machine,
precise textile machine, logistic system

Features:

• MPU points:16 / 20 / 24 / 32 / 40 / 60
• Program capacity: 16k steps
• Built-in with 3 COM ports: 1 RS-232 port and 2 RS-485 ports, all are able to
  operate independently (Master/Slave)
• Max. I/O points: 256 input points + 16 output points, or 256 output points + 16 input points

ES2 Series – 220VAC

Applications

HVAC, molding injection machine, big storage management, packaging machine, precise textile machine, logistic system

Features:

• MPU points:16 / 20 / 24 / 32 / 40 / 60
• Program capacity: 16k steps
• Built-in with 3 COM ports: 1 RS-232 port and 2 RS-485 ports, all are able to operate independently (Master/Slave)
• Max. I/O points: 256 input points + 16 output points, or 256 output points + 16 input points
• DVP-EX2 MPU is built in with 12-bit 4AD/2DA and offers analog/temperature modules of 14-bit resolution
• Built-in with 8 high-speed input points (2 points for 100kHz, 6 points for 10kHz) and supports U/D, U/D Dir, A/B counting modes
• New motion control instructions: Close loop control, alignment mark, shield, immediate variable speed, S-Curve acceleration/deceleration
• Application in emerging industry:Exclusive instructions and function blocks designed for PV solar tracker
• Handy instructions for frequency inverter: For controlling the forward running, reverse running, RUN and STOP of Delta's AC motor drives
• Password protection:Password for subroutine, user ID, restriction on trial times
• Highly efficient instruction efficient instruction execution

Range: Single Phase – 0.025HP to 3HP

Range: Three Phase – 0.5HP to 5HP

EC3 series

Applications

Single control unit, landscape fountain, building automation

Specifications:

• MPU points: 10/ 14 / 16 / 24 / 32 / 60
• I/O points: 60
• Program capacity: 4k steps
• COM ports: Built-in RS-232 and RS-485 ports (available in 16-60 point models); compatible with Modbus ASCII/RTU protocol
• Built-in 4 points of high-speed counters*:

PLC AS Series

Applications

Smaller cranes; washing machines; treadmilsl; robot arm of injection machine (clamp); elevator; grinding machine; drilling machine; wood machine; webbing loom; air conditioner for large buildings; water supply system for large buildings, etc.

Specifications:

• New 32-bit SoC (System on Chip) CPU
• I/O: 1,024
• Program capacity: AS300 series 128k steps, AS200 series 64k steps
• Data registers: 60k words
• Extension modules: max. 32 (analog modules: max.16 / communication modules: max. 4)
• Execution speed: up to 40 k steps / ms
• – Basic instruction (LD): 25 ns
• – Application instruction (MOV): 0.15 μs
• Abundant selection of DIO modules, AIO modules, temperature modules, load cell module and function cards.

SV2 Series

Applications

Smaller cranes; washing machines; treadmilsl; robot arm of injection machine (clamp); elevator; grinding machine; drilling machine; wood machine; webbing loom; air conditioner for large buildings; water supply system for large buildings, etc.

Specifications:

• New 32-bit SoC (System on Chip) CPU
• I/O: 1,024
• Program capacity: AS300 series 128k steps, AS200 series 64k steps
• Data registers: 60k words
• Extension modules: max. 32 (analog modules: max.16 / communication modules: max. 4)
• Execution speed: up to 40 k steps / ms
• – Basic instruction (LD): 25 ns
• – Application instruction (MOV): 0.15 μs
• Abundant selection of DIO modules, AIO modules, temperature modules, load cell module and function cards.
